Product Details
＋
| Product Attribute | Attribute Value |
|---|---|
| Alternate Mfr Part Number | M2510000 |
| Body Style | Cylindrical |
| Connection Type | Screw 4-Wire |
| Current, Switching | 200 mA |
| Frequency, Switching | 100 Hz |
| Function | Level |
| Housing Material | PBT |
| Indicator | Yellow LED (Output), Green LED (Power) |
| IP Rating | IP67 |
| Measurement Range | 20 mm |
| Mounting Type | M40 Flush |
| Output | PNP-NO/NC |
| Primary Type | Capacitive Proximity Sensors |
| Series | |
| Shielding | Shielded |
| Standards | UL Listed, CSA Certified |
| Supply Voltage | 65 VDC |
| Technology | Capacitive |
| Temperature, Ambient, Maximum | 70 °C |
| Temperature, Ambient, Minimum | -25 °C |
| Termination | Wired Connector |
| Type | Capacitive |
Overview
10 to 65 VDC, Capacitive Sensors - Barrels
Capacitive sensors were originally designed for use in level detection applications in areas that were generally far away from other electrical equipment. As factory automation has become more prevalent throughout industrial markets, these capacitive sensors have gravitated into new environments where electrical noise levels are greater. TURCK recognized this development and reacted by introducing the “BCF” series of sensors which incorporate a unique filter principle, making them immune to most industrial noise.
Features
Specifications
